SICK PBT-RM025AG1MSNALA0Z (6051008) — PRESSURE SENSOR

A SICK pressure sensor for precise measurement of gauge, absolute, or differential pressure in industrial process applications.

• Measuring range: 0 MPa ... 25
• Accuracy: ? ± 0.5 % of the span
• Non-linearity: ? ± 0.25 %, (Best Fit Straight Line, BFSL) according to IEC 61298-2
• Process connection: G ¼ A according to DIN 3852-
• Pressure port: 0.6 mm pressure port
• Process temperature: 0 °C ... +80 °
• Output signal: 4 mA ... 20 mA, 2-wire
• Connection type: L-connector acc. to DIN 175301-803
• Enclosure rating: IP65
