Sick PBT-AB1X0SGESECALA0Z (6078695)

Pressure sensors PBT, PBT-AB1X0SGESECALA0Z Pressure type: Absolute pressure Pressure unit: bar Measuring range: 0 bar ... 1 bar Accuracy: ? ± 1 % of the span Non-linearity: ? ± 0.5 %, of the span Process connection: G ½ B according to EN 837 Pressure port: Standard Process temperature: –30 °C ... +100 °C Seal: Copper Output signal: 4 mA ... 20 mA, 2-wire Connection type: L-connector acc. to DIN 175301-803 A Enclosure rating: IP65 Supply voltage: 8 V DC ... 30 V DC Specialty: Without
