SICK PBT-AB016SGESSSAMA0Z (6078774) — PRESSURE SENSOR

A SICK pressure sensor for precise measurement of gauge, absolute, or differential pressure in industrial process applications.

• Pressure unit: bar
• Measuring range: 0 bar ... 16 bar
• Accuracy: ? ± 1 % of the span
• Non-linearity: ? ± 0.5 %, of the span
• Process connection: G ½ B according to EN 837
• Process temperature: 0 °C ... +80 °
• Output signal: 4 mA ... 20 mA, 2-wire
• Connection type: M12 round connector x 1, 4-pin
• Enclosure rating: IP67
