SICK PBS2-CB1X0SG2SS0Q5A0Z (6074230) — PRESSURE SENSOR

A SICK pressure sensor for precise measurement of gauge, absolute, or differential pressure in industrial process applications.

• Pressure unit: bar
• Measuring range: –1 bar ... 0 bar–14.5 psi ... 0 psi
• Accuracy: ? ± 0.5 % of the span
• Process connection: G ¼ female
• Pressure port: 3.5 mm
• Process temperature: –20 °C ... +85 °
• Output signal: IO-Link/PNP/NPN + PNP/NPN + 4 mA ... 20 mA / 0 V ... 10
• Connection type: Round connector M12 x 1, 5-pin
• Enclosure rating: IP67, IP67
• Supply voltage: 15 V DC ... 35 V DC
