SICK C4P-EA06031CA0 (1116218) — SAFETY LIGHT CURTAIN

A SICK safety light curtain for reliable personnel protection, detecting the presence of hands, fingers, or bodies in hazardous machine zones.

• Product version: deTec4
• Safety level: PL e, SIL 3, Type 4
• Resolution: 30 mm
• Scanning range: 30 m
• Protective field height: 600 mm
• Connection type: Male connector M12, 5-pin
• Extension connection: –
• Enclosure rating: IP65IP67
• Items supplied: Receiver with preassembled system plug 1000 (SP1, M12, 5-pin)Test rod with diameter corresponding to the resolution of the safety light curtainSafety instructionMounting instructionsOperating instructions for download
